#Arduino Prototype Component

#include  //import capacitive sensing library
#include "DHT.h"
#define DHTPIN 2
#define DHTTYPE DHT11
DHT dht(DHTPIN, DHTTYPE);
int ref0;
int led1 = 13;
int led2 = 12;
void setup() {
  // put your setup code here, to run once:
  Serial.begin(9600); // *initialization - make the connection to the UNO board
  //Serial.println(F("DHTxx test!"));
  dht.begin();

  ref0 = ADCTouch.read(A0, 500); //Initial reference value

//  pinMode(led1, OUTPUT);
//  pinMode(led2, OUTPUT);

}
void loop() {
  // put your main code here, to run repeatedly:
  int value0 = ADCTouch.read(A0); // Read value of pin A0
  value0 = value0 - ref0;
  //Serial.print (",");
  //delay(10);
  delay(100);

  float h = dht.readHumidity();
  float t = dht.readTemperature();
  float f = dht.readTemperature(true);
  // Check if any reads failed and exit early (to try again).
  if (isnan(h) || isnan(t) || isnan(f)) {
    Serial.println(F("Failed to read from DHT sensor!"));
    return;
  }
  // Compute heat index in Fahrenheit (the default)
  //float hif = dht.computeHeatIndex(f, h);
  // Compute heat index in Celsius (isFahreheit = false)
  //float hic = dht.computeHeatIndex(t, h, false);

  if (value0 > 30) {
    digitalWrite (led1, HIGH);
    digitalWrite (led2, LOW);
  }
  else {
    digitalWrite(led1, LOW);
    digitalWrite(led2, HIGH);
  }
 Serial.print(value0);
 Serial.print(',');
 Serial.print(h);
 Serial.print(',');
 Serial.println(t);
// Serial.print(',');
// Serial.println(f);
//  Serial.print(F("Conductive Value: "));
//  Serial.print(value0);
//  Serial.print(F(" Humidity: "));
//  Serial.print(h);
//  Serial.print(F("%  Temperature: "));
//  Serial.print(t);
//  Serial.print(F("C "));
//  Serial.print(f);
//  Serial.print(F("F  Heat index: "));
//  Serial.print(hic);
//  Serial.print(F("C "));
//  Serial.print(hif);
//  Serial.println(F("F"));

//  digitalWrite (led1, HIGH);
//  digitalWrite (led2, LOW);
//  delay(2000);
//  digitalWrite(led1, LOW);
//  digitalWrite(led2, HIGH);
//  delay(200);
//remember to check tools => board + port

}

#Arduino Prototype Component

#include  //import capacitive sensing library
#include "DHT.h"
#define DHTPIN 2
#define DHTTYPE DHT11
DHT dht(DHTPIN, DHTTYPE);
int ref0;
int led1 = 13;
int led2 = 12;
void setup() {
  // put your setup code here, to run once:
  Serial.begin(9600); // *initialization - make the connection to the UNO board
  //Serial.println(F("DHTxx test!"));
  dht.begin();

  ref0 = ADCTouch.read(A0, 500); //Initial reference value

//  pinMode(led1, OUTPUT);
//  pinMode(led2, OUTPUT);

}
void loop() {
  // put your main code here, to run repeatedly:
  int value0 = ADCTouch.read(A0); // Read value of pin A0
  value0 = value0 - ref0;
  //Serial.print (",");
  //delay(10);
  delay(100);

  float h = dht.readHumidity();
  float t = dht.readTemperature();
  float f = dht.readTemperature(true);
  // Check if any reads failed and exit early (to try again).
  if (isnan(h) || isnan(t) || isnan(f)) {
    Serial.println(F("Failed to read from DHT sensor!"));
    return;
  }
  // Compute heat index in Fahrenheit (the default)
  //float hif = dht.computeHeatIndex(f, h);
  // Compute heat index in Celsius (isFahreheit = false)
  //float hic = dht.computeHeatIndex(t, h, false);

  if (value0 > 30) {
    digitalWrite (led1, HIGH);
    digitalWrite (led2, LOW);
  }
  else {
    digitalWrite(led1, LOW);
    digitalWrite(led2, HIGH);
  }
 Serial.print(value0);
 Serial.print(',');
 Serial.print(h);
 Serial.print(',');
 Serial.println(t);
// Serial.print(',');
// Serial.println(f);
//  Serial.print(F("Conductive Value: "));
//  Serial.print(value0);
//  Serial.print(F(" Humidity: "));
//  Serial.print(h);
//  Serial.print(F("%  Temperature: "));
//  Serial.print(t);
//  Serial.print(F("C "));
//  Serial.print(f);
//  Serial.print(F("F  Heat index: "));
//  Serial.print(hic);
//  Serial.print(F("C "));
//  Serial.print(hif);
//  Serial.println(F("F"));

//  digitalWrite (led1, HIGH);
//  digitalWrite (led2, LOW);
//  delay(2000);
//  digitalWrite(led1, LOW);
//  digitalWrite(led2, HIGH);
//  delay(200);
//remember to check tools => board + port

}

#Processing Feature

import processing.serial.*; // importing processing serial library for connecting with arduino
Serial myPort; //usb port

String val; //incoming data from arduino as character - string
String[] stringData;
float v, h, t;
int sensorVal; //we use this variable for the data as number type

float angle = 0;
float sunMovement = 0;
float accum_v = 0;

float sun_color = 0;
float sun_radiate = 120;
float sun_radiate_alpha = 255;


//Egg egg1;
float tiltAmp = 1;
PImage grass01;
PImage grass02;
PImage grass03;
PImage grass04;

PImage egg01;
PImage egg02;
PImage egg03;
PImage egg04;

int x = 0;
int y = 0;

float spacing = 20;
float diameter = 10;

void setup(){
  size(displayWidth, displayHeight);
  //egg1 = new Egg(displayWidth/2, displayHeight/2, 0, 150);

  String portName = "/dev/cu.usbmodem14301"; //find port name in arduino sogtware and put it here
  myPort = new Serial(this, portName, 9600); //create serial connection
  myPort.bufferUntil('\n');

  //load all image
  grass01 = loadImage("Grass01.png");
  grass02 = loadImage("Grass02.png");
  grass03 = loadImage("Grass03.png");
  grass04 = loadImage("Grass04.png");

  egg01 = loadImage("Egg01.png");
  egg02 = loadImage("Egg02.png");
  egg03 = loadImage("Egg03.png");
  egg04 = loadImage("Egg04.png");

}

void draw(){
  background(255);
  float n = width / spacing;
  float a = 1;

  //floor
  noStroke();
  fill(245);
  rect(0, 280, displayWidth, 540);

  //floor dot pattern
    for (var i = 0; i < n; i++) {
      for (var j = 0; j < n; j++) {
        a *= -1;
        var x = i * spacing;
        var y = j * spacing;
        if(a > 0){
          x = x + spacing / 2;
        }
          var d = diameter;
          fill(255);
        ellipse(x, y, d, d);
      }
    }

  //sun movement
  if(sunMovement <= 100){
    sunMovement += 0.15;
  }


  if(v > 7){
    noStroke();
    fill(203 - sun_color, 64 + sun_color, 66 + sun_color * 1.5, sun_radiate_alpha);
    ellipse(1100 + sunMovement, 150 + sunMovement, sun_radiate, sun_radiate);
  }
  //noStroke();
  //fill(203 - sun_color, 64 + sun_color, 66 + sun_color * 1.5, sun_radiate_alpha);
  //ellipse(1100 + sunMovement, 150 + sunMovement, sun_radiate, sun_radiate);
  noStroke();
  fill(203 - sun_color, 64 + sun_color, 66 + sun_color * 1.5);
  ellipse(1100 + sunMovement, 150 + sunMovement, 120, 120);

  if(sun_radiate < 200) {
    sun_radiate += 2;
  }
  else {
    sun_radiate = 120;
  }

    if(sun_radiate_alpha > 0) {
    sun_radiate_alpha -= 6.375;
  }
  else {
    sun_radiate_alpha = 255;
  }

  //grass backward
  image(grass04, 371, 230, 575, 246);
  image(grass03, 695, 328, 627, 217);

  angle += 0.05;
  //egg position and rotation
  pushMatrix();
  translate(displayWidth/2, displayHeight/2 + 100);

  noStroke();
  fill(220);
  ellipse(0 + cos(angle) * 10, 0, 160, 30);

  scale(0.3);
  rotate(cos(angle) / 8 * tiltAmp);
  image(egg01, x - egg01.width/2, y - egg01.height);
  popMatrix();
  //egg1.display();

  //grass frount
  image(grass02, 946, 594, 252, 172);
  image(grass01, 390, 467, 348, 221);


  //arduino data loading
  while (myPort.available() > 0){
    val = myPort.readStringUntil('\n'); // reads it and stores it in val; \n is the line break
    //try{
    //  //val = myPort.readString();
    //  stringData = split(val, ',');
    //  //sensorVal = Integer.valueOf(val.trim()); // converts the text strin into a number
    //}
    //catch(Exception e){
    //}
    }
  if (val != null) {
    stringData = split(val, ',');
    float[] values = float(stringData);
    v = values[0];
    h = values[1];
    t = values[2];
  }

  //egg tilt value
  tiltAmp = 1 + v / 20;

  //sun color change
  sun_color = (h - 50) * 2;

  //loading bar accumulation
  if(v >= 30){
    if(accum_v < 250){
      accum_v = accum_v + v * 0.01;
    }
    else {
      accum_v = 250;
    }
  }



  //temperature bar
  float pos_x = - 180;
  float pos_y = 0;
  float sphere_d = 30;
  float rect_w = 20;
  float rect_h = 120;
  float thickness = 8;
  float sphere_d_in = 30 - thickness;
  float rect_w_in = 20 - thickness;
  float rect_h_in = 120 - thickness + 4;
  float sphere_d_out = 30 + thickness - 4;
  float rect_w_out = 20 + thickness - 4;
  float rect_h_out = 120 + thickness - 6;
  float sphere_red = 30 - 1.5 * thickness;
  float rect_w_red = 20 - 1.5 * thickness;
  float rect_h_red = 120 - 1.5 * thickness + 6;

  float dist = 120 - (t - 26) * 50;

  if(dist < 0) {
    dist = 0;
  }
  else if (dist > rect_h_red){
    dist = rect_h_red;
  }

  pushMatrix();
  translate(displayWidth/2, displayHeight/2);

  noStroke();

  fill(255);
  ellipse(pos_x, pos_y, sphere_d_out, sphere_d_out);
  rect(pos_x - rect_w_out / 2, pos_y - rect_h_out, rect_w_out, rect_h_out, 10);
  fill(220);
  ellipse(pos_x, pos_y, sphere_d, sphere_d);
  rect(pos_x - rect_w / 2, pos_y - rect_h, rect_w, rect_h, 10);
  fill(255);
  ellipse(pos_x, pos_y, sphere_d_in, sphere_d_in);
  rect(pos_x - rect_w_in / 2, pos_y - rect_h_in, rect_w_in, rect_h_in, 10);
  fill(#cb4042);
  ellipse(pos_x, pos_y, sphere_red, sphere_red);
  rect(pos_x - rect_w_red / 2, pos_y - rect_h_red + dist, rect_w_red, rect_h_red - dist, 10);
  popMatrix();

  //loading bar
  stroke(255);
  strokeWeight(8);
  fill(255);
  rect(displayWidth/2 - 130, displayHeight/2 + 140, 260, 40, 10);

  noStroke();
  fill(#FFC408);
  rect(displayWidth/2 - 125, displayHeight/2 + 145, accum_v, 30, 7);

  stroke(220);
  strokeWeight(4);
  noFill();
  rect(displayWidth/2 - 130, displayHeight/2 + 140, 260, 40, 10);




  //tiltAmp = 1 + v / 100;
  //egg1.wobble();

  //print(displayWidth);
  //print(displayHeight);

  print(cos(angle) / 8 * tiltAmp);
  print(',');
  print(v);
  print(',');
  print(h);
  print(',');
  println(t);

}



class Egg {
  float x, y; // X-coordinate, y-coordinate
  float tilt; // Left and right angle offset
  float angle; // Used to define the tilt
  float scalar; // Height of the egg

  // Constructor
  Egg(float xpos, float ypos, float t, float s) {
    x = xpos;
    y = ypos;
    tilt = t;
    scalar = s / 100.0;
  }

  void wobble() {
    tilt = cos(angle) / 8 * tiltAmp;
    angle += 0.1;
  }

  void display() {
    noStroke();
    fill(200);
    pushMatrix();
    translate(x, y);
    rotate(tilt);
    scale(scalar);
    beginShape();
    vertex(0, -100);
    bezierVertex(25, -100, 40, -65, 40, -40);
    bezierVertex(40, -15, 25, 0, 0, 0);
    bezierVertex(-25, 0, -40, -15, -40, -40);
    bezierVertex(-40, -65, -25, -100, 0, -100);
    endShape();
    popMatrix();
  }
}

#The Camera Component

import machine
import time
import network
import dht
from umqtt.simple import MQTTClient

def set_pin(*num):
    list_num = []
    for item in num:
        pin_id = machine.Pin(item, machine.Pin.IN, machine.Pin.PULL_UP)
        list_num.append(pin_id)
    return list_num


def read_value(list_knob):
    list_value = []
    for item in range(len(list_knob)):
        list_value.append(list_knob[item].value())
    return list_value


def set_result(import_list):

    export_value = 0

    if import_list == [1, 1, 1, 1]:
        export_value = 0
    elif import_list == [0, 1, 1, 1]:
        export_value = 1
    elif import_list == [1, 0, 1, 1]:
        export_value = 2
    elif import_list == [0, 0, 1, 1]:
        export_value = 3
    elif import_list == [1, 1, 0, 1]:
        export_value = 4
    elif import_list == [0, 1, 0, 1]:
        export_value = 5
    elif import_list == [1, 0, 0, 1]:
        export_value = 6
    elif import_list == [0, 0, 0, 1]:
        export_value = 7
    elif import_list == [1, 1, 1, 0]:
        export_value = 8
    elif import_list == [0, 1, 1, 0]:
        export_value = 9

    return export_value


def internet_connect():
    # connect the ESP to local wifi network
    #
    yourWifiSSID = "ACCD"
    yourWifiPassword = "tink1930"
    sta_if = network.WLAN(network.STA_IF)
    if not sta_if.isconnected():
      sta_if.active(True)
      sta_if.connect(yourWifiSSID, yourWifiPassword)
      while not sta_if.isconnected():
        pass

    print("connected to WiFi")


def light_detect(pin_id):
    adc1 = machine.ADC(machine.Pin(pin_id))
    adc1.atten(machine.ADC.ATTN_11DB)
    return adc1


def light_convert(num):
    if num < 1500:
        result_value = 0
    elif num < 2000:
        result_value = 1
    elif num < 2500:
        result_value = 2
    elif num < 3000:
        result_value = 3
    elif num < 3500:
        result_value = 4
    elif num < 4000:
        result_value = 5
    else:
        result_value = 6

    return result_value


def hum_detect():
    global temp
    global hum
    global temp_f
    sensor.measure()
    temp = sensor.temperature()
    hum = sensor.humidity()
    temp_f = temp * (9/5) + 32.0


internet_connect()
#
# connect ESP to Adafruit IO using MQTT
#
myMqttClient = "itdoesnotmatter"  # replace with your own client name
adafruitUsername = "fqhang"  # can be found at "My Account" at adafruit.com
adafruitAioKey = "f8c8109354ca4d83b7a702d9101b2fc4"  # can be found by clicking on "VIEW AIO KEYS" when viewing an Adafruit IO Feed
adafruitFeed1 = adafruitUsername + "/feeds/KnobValue1" # replace "test" with your feed name
adafruitFeed2 = adafruitUsername + "/feeds/KnobValue2" # replace "test" with your feed name
adafruitFeed3 = adafruitUsername + "/feeds/PhotoSensor" # replace "test" with your feed name
adafruitFeed4 = adafruitUsername + "/feeds/Temperature" # replace "test" with your feed name
adafruitFeed5 = adafruitUsername + "/feeds/Humidity" # replace "test" with your feed name
adafruitFeed6 = adafruitUsername + "/feeds/Switch"
adafruitIoUrl = "io.adafruit.com"
c = MQTTClient(myMqttClient, adafruitIoUrl, 0, adafruitUsername, adafruitAioKey)


button = machine.Pin(12, machine.Pin.IN, machine.Pin.PULL_UP)
photo_int = light_detect(34)

knob_green = set_pin(26, 25, 4, 14)
knob_white = set_pin(27, 33, 15, 32)

sensor = dht.DHT22(machine.Pin(13, machine.Pin.IN, machine.Pin.PULL_UP))

list_value1 = read_value(knob_white)
knob_value3 = set_result(list_value1)

list_value2 = read_value(knob_green)
knob_value4 = set_result(list_value2)

c.connect()

while True:

    list_value1 = read_value(knob_white)
    knob_value1 = set_result(list_value1)

    list_value2 = read_value(knob_green)
    knob_value2 = set_result(list_value2)

    print(knob_value1)
    print(knob_value2)

    knob1_difference = knob_value1 - knob_value3
    knob2_difference = knob_value2 - knob_value4

    if knob1_difference != 0:
        print("difference" + str(knob_value1))
        c.publish(adafruitFeed6, str(knob_value1) + str(knob_value2))
        list_value1 = read_value(knob_white)
        knob_value3 = set_result(list_value1)

    if knob2_difference != 0:
        print("difference" + str(knob_value2))
        c.publish(adafruitFeed6, str(knob_value1) + str(knob_value2))
        list_value2 = read_value(knob_green)
        knob_value4 = set_result(list_value2)

    time.sleep(0.5)

    if not button.value():

        list_value1 = read_value(knob_white)
        knob_value1 = set_result(list_value1)

        list_value2 = read_value(knob_green)
        knob_value2 = set_result(list_value2)

        photo_value = light_convert(photo_int.read())

        hum_detect()

        c.publish(adafruitFeed1, str(knob_value1))
        c.publish(adafruitFeed2, str(knob_value2))
        c.publish(adafruitFeed3, str(photo_value))
        c.publish(adafruitFeed4, str(temp_f))
        c.publish(adafruitFeed5, str(hum))

        print(list_value1)
        print(knob_value1)
        print(list_value2)
        print(knob_value2)
        print(photo_int.read())
        print(photo_value)
        print('Temperature: %3.1f C' %temp)
        print('Temperature: %3.1f F' %temp_f)
        print('Humidity: %3.1f %%' %hum)
        time.sleep(0.5)

# 1.upload the data to the cloud
# 2.control two switches at the same time
# 3.connect to the esp32 to detect the sensors and print the variables
# 4.write classes

# The Base Component

import machine
import time
import network
import ssd1306
from umqtt.simple import MQTTClient

# OLED Display

def initDisplay():
    print("initDisplay called.")
    oled.init_display()
    oled.fill(0)
    oled.text("Hello" , 0, 0)
    oled.text("Welcome to" , 0, 10)
    oled.text("Instaportal" , 0, 20)
    oled.show()

def internet_connect():
    # connect the ESP to local wifi network
    #
    yourWifiSSID = "ACCD"
    yourWifiPassword = "tink1930"
    sta_if = network.WLAN(network.STA_IF)
    if not sta_if.isconnected():
      sta_if.active(True)
      sta_if.connect(yourWifiSSID, yourWifiPassword)
      while not sta_if.isconnected():
        pass

    print("connected to WiFi")


def sub_cb(topic, msg):
    global value
    value = list(str(msg,'utf-8'))
    print(value)

def obj_mode(int):
    if int == '0':
        oled.text("LandScape Mode", 0, 0)
    elif int == '1':
        oled.text("Portrait Mode", 0, 0)
    elif int == '2':
        oled.text("Animal Mode", 0, 0)
    elif int == '3':
        oled.text("Plant Mode", 0, 0)
    elif int == '4':
        oled.text("Sky Mode", 0, 0)
    elif int == '5':
        oled.text("Architecture Mode", 0, 0)
    elif int == '6':
        oled.text("Furniture Mode", 0, 0)
    elif int == '7':
        oled.text("Prairie Mode", 0, 0)
    elif int == '8':
        oled.text("Space Mode", 0, 0)
    elif int == '9':
        oled.text("Illusion Mode", 0, 0)

def mood_mode(int):
    if int == '0':
        oled.text("Happy Mode", 0, 10)
    elif int == '1':
        oled.text("Cry Mode", 0, 10)
    elif int == '2':
        oled.text("Blue Mode", 0, 10)
    elif int == '3':
        oled.text("Angry Mode", 0, 10)
    elif int == '4':
        oled.text("Casual Mode", 0, 10)
    elif int == '5':
        oled.text("Excited Mode", 0, 10)
    elif int == '6':
        oled.text("Crazy Mode", 0, 10)
    elif int == '7':
        oled.text("Desired Mode", 0, 10)
    elif int == '8':
        oled.text("Relax Mode", 0, 10)
    elif int == '9':
        oled.text("Scare Mode", 0, 10)


i2c = machine.I2C(scl=machine.Pin(22), sda=machine.Pin(23), freq = 100000)
oled = ssd1306.SSD1306_I2C(128, 32, i2c)
initDisplay()

internet_connect()
value = []
#
# connect ESP to Adafruit IO using MQTT
#
myMqttClient = "esp32"  # replace with your own client name
adafruitUsername = "fqhang"  # can be found at "My Account" at adafruit.com
adafruitAioKey = "f8c8109354ca4d83b7a702d9101b2fc4"  # can be found by clicking on "VIEW AIO KEYS" when viewing an Adafruit IO Feed
adafruitFeed1 = adafruitUsername + "/feeds/Switch" # replace "test" with your feed name
adafruitIoUrl = "io.adafruit.com"
c = MQTTClient(myMqttClient, adafruitIoUrl, 0, adafruitUsername, adafruitAioKey)

c.connect()
while True:
    time.sleep(0.5)
    c.set_callback(sub_cb)
    c.subscribe(bytes(adafruitFeed1,'utf-8'))
    c.check_msg()

    if len(value) == 2:
        oled.fill(0)
        obj_mode(value[0])
        mood_mode(value[1])
        oled.text("@instaportal", 0, 20)
        oled.show()
